EFB0412LD-R00
RoHS
RoHS compliant
RoHS compliantPackage Axial
Category Fans, Thermal Management / DC Brushless Fans (BLDC)
Description
40X40X20MM 12V DC FAN W/ SPEED SENSOR (LOCK)
PDF
/
Inventory: 9818
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Height 40mm
Technical
Static Pressure 0.136 in H2O (33.9 Pa)
Voltage Range 7V~13.8VDC
Noise 22.0 dB(A)
Air Flow 5.5 CFM (0.154m3/min)
Fan Type Tubeaxial
Bearing Type Ball
RPM 5000 RPM
Life (Hours) 70000 hours
Lifetime @ Temp 70000 Hrs @ 40°C
Approval Agency CE, CSA, UL, VDE
Current Rating 50mA
Max Power Dissipation 600mW
Current Rating (Amps) 0.050A
Power Rating 600mW
Voltage - Rated 12VDC
Termination 3 Wire Leads
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Locked Rotor Sensor
Size / Dimension Square - 40mm Lx40mm H
Series EFB
Published 2004
Operating Temperature 14~158°F -10°C~70°C
Physical
Material - Frame Plastic
Weight 0.073lb 33.11g
Package / Case Axial
Supply Chain
Factory Lead Time 19 Weeks
