MCP4551-502E/MS
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP4551 Mute Selectable Address I2C e3 digital potentiometer 5V 5kOhm 950mum 2.5muA
PDF
/
Buying Options
Total Price: USD $1.06
Unit Price: USD $1.056
≥1 USD $1.056
≥10 USD $0.88
≥100 USD $0.7832
Inventory: 439
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 3mm
Length 3mm
Height 950μm
Technical
Resistance - Wiper (Ω) (Typ) 75
Number of Taps 257
Taper Linear
Memory Type Volatile
Nominal Supply Current 2.5μA
Number of Circuits 1
Interface I2C
Configuration Potentiometer
Operating Supply Voltage 5V
Pin Count 8
Base Part Number MCP4551
Time@Peak Reflow Temperature-Max (s) 40
Terminal Pitch 0.635mm
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 1.8V~5.5V
Technology CMOS
Terminal Finish Matte Tin (Sn) - annealed
Number of Positions 256
Resistance 5kOhm
Temperature Coefficient 150 ppm/°C
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Mute, Selectable Address
JESD-609 Code e3
Tolerance ±20%
Published 2008
Packaging Tube
Operating Temperature -40°C~125°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 8 Weeks
