MCP42100T-E/SL
RoHS
RoHS compliant
RoHS compliantPackage 14-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Data Acquisition - Digital Potentiometers
Description
MCP42100 Cascade Pin SPI e3 digital potentiometer 0.145kHz 3/5V 100kOhm 8.65mm
PDF
/
Buying Options
Total Price: USD $1.96
Unit Price: USD $1.964098
≥1 USD $1.964098
≥200 USD $0.760169
≥500 USD $0.733911
≥1000 USD $0.720782
Inventory: 1497
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 14-SOIC (0.154, 3.90mm Width)
Number of Pins 14
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2003
Tolerance ±30%
JESD-609 Code e3
Feature Cascade Pin
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 14
ECCN Code EAR99
Temperature Coefficient 800 ppm/°C
Resistance 100kOhm
Number of Positions 256
Terminal Finish Matte Tin (Sn)
Technology CMOS
Voltage - Supply 2.7V~5.5V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 2
Supply Voltage 5V
Frequency 10MHz
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number MCP42100
Pin Count 14
Power Supplies 3/5V
Configuration Potentiometer
Interface SPI
Number of Circuits 2
Nominal Supply Current 340μA
Memory Type Volatile
Quiescent Current 10nA
Bandwidth 0.145 kHz
Taper Linear
Number of Taps 256
Total Resistance 100000Ohm
Resistance - Wiper (Ω) (Typ) 175
Resistor Terminal Voltage-Max 5V
Dimensions
Height Seated (Max) 1.75mm
Length 8.65mm
Width 3.9mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
