AFE1302Y/250
RoHS
RoHS compliant
RoHS compliantPackage 48-TQFP
Category Integrated Circuits (ICs) / Data Acquisition - Analog Front End (AFE)
Description
QUAD Obsolete COMMERCIAL GULL WING AFE 2B 7mm 500mW 70C
PDF
/
Buying Options
Total Price: USD $28.74
Unit Price: USD $28.7375
≥1 USD $28.7375
≥10 USD $23.57995
≥100 USD $22.84275
≥500 USD $22.1065
≥1000 USD $21.3693
Inventory: 4507
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 7mm
Length 7mm
Technical
Telecom IC Type DIGITAL SLIC
Voltage - Supply, Digital 3V~5.5V
Voltage - Supply, Analog 5V
Resolution 2 B
Number of Bits 16
Min Supply Voltage 4.75V
Max Supply Voltage 5.5V
Number of Channels 1
Temperature Grade COMMERCIAL
Power Supplies 3.35V
Pin Count 48
Base Part Number AFE1302
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Form GULL WING
Terminal Position QUAD
Max Power Dissipation 500mW
Power Rating 500mW
Subcategory Other Telecom ICs
Power (Watts) 570mW
Min Operating Temperature 0°C
Max Operating Temperature 70°C
Number of Terminations 48
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
Pbfree Code no
Packaging Cut Tape (CT)
Physical
Weight 137.410139mg
Number of Pins 48
Surface Mount YES
Package / Case 48-TQFP
