3357-6525-1C
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Backshells, Hoods
Description
3M 3357-6525-1C D Sub Backshell, Shielded, 3357 Series, DB, ABS (Acrylonitrile Butadiene Styrene) Body
PDF
/
Inventory: /
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 53.1mm
Length 53.1mm
Technical
Hardware Assembly Hardware, Strain Relief
Cable Exit 45°
Wire/Cable Diameter 11.43 mm
Accessory Type Two Piece Backshell
Wire/Cable Type Round
Cable Type Round
Plating Nickel over Copper
Depth 18mm
Shielding Shielded
Orientation Straight
Color Silver
Min Operating Temperature 0°C
Max Operating Temperature 75°C
Number of Positions 25
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Mating Screws 4-40
Series 3357
Published 2005
Physical
Body Material ABS
Weight 2.267962kg
Housing Material ABS
Material Acrylonitrile Butadiene Styrene (ABS)
Shell Material ABS
Supply Chain
Factory Lead Time 14 Weeks
