243A10140X
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub, D-Shaped Connectors - Adapters
Description
Conn Filtered D-Sub Adapter PIN/SKT 50/50 POS ST 1 Port
PDF
/
Inventory: 4179
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Technical
Rated Current (Signal) 5A
Contact Style RND PIN-SKT
Body/Shell Style PLUG/RECEPTACLE
Dielectric Withstanding Voltage 424VDC V
Connector Style Connector Saver
Number of Ports 1
PCB Contact Row Spacing 2.8448 mm
Max Voltage Rating (DC) 100V
Contact Pattern STAGGERED
Withdrawl Force-Min 2.224 N
Includes 3 pcs - 1 Connector, 2 Jack Screws
Convert From (Adapter End) D-Sub, 50 Pin Male
Convert To (Adapter End) D-Sub, 50 Pin Female
Max Supply Voltage (DC) 100V
Gender Type A Male
Gender Type B Female
Housing Color Black
Body Breadth 0.62 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 3
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish TIN OVER NICKEL
Current Rating 7.5A
Terminal Pitch 2.7686mm
Ingress Protection IP20
Orientation Straight
Total Number of Contacts 50
Filter Feature YES
Subcategory D Type Connectors
Additional Feature ADAPTER
Number of Rows 3
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Feature Filter
Series 243A
Published 2005
Operating Temperature -25°C~105°C
Dimensions
Length 67.31mm
Contact Finish Thickness 8.00μin 0.203μm
Compliance
Material Flammability Rating UL94 V-0
Radiation Hardening No
RoHS Status ROHS3 Compliant
Physical
Shell Material, Finish Steel, Tin Plated
Housing Material Polyester
Number of Pins 50
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material COPPER ALLOY
Supply Chain
Factory Lead Time 12 Weeks
