1757821-8
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
AMPLIMITE,ASY,PLUG,FB,109,ZN,3,CONT
PDF
/
Inventory: 5642
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status RoHS Compliant
Technical
Contact Design PREASSEM CONN
Hole Diameter 2.3114 mm
Circuit Application Signal
Sealable No
Contact Pattern STAGGERED
Number of Ports 1
Plating Zinc
Shell Size 3/B
ELV Compliant
Contact Style Crimp
Empty Shell NO
Operating Temperature (Min) -55°C
Body Breadth 0.509 inch
Reliability COMMERCIAL
Current Rating 7.5A
Orientation Straight
Total Number of Contacts 25
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Additional Feature AMPLIMITE, STANDARD: MIL-C-24308
Gender Male
Number of Rows 2
Connector Type Pin, Plug
ECCN Code EAR99
Number of Terminations 25
Packaging Bulk
Physical
Shell Material Steel
Insulation Material POLYESTER
Mount Cable
Contact Plating Gold, Nickel
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 1 week ago)
