DBMM25SDNMB
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 25POS R/A SOLDER
PDF
/
Buying Options
Total Price: USD $45.1
Unit Price: USD $45.101942
≥1 USD $45.101942
≥10 USD $42.549004
≥100 USD $40.140569
≥500 USD $37.868458
≥1000 USD $35.724959
Inventory: 3079
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.127 inch
Plating Thickness 50μin
Technical
Insulator Color WHITE
Contact Pattern STAGGERED
PCB Contact Row Spacing 2.8448 mm
Dielectric Withstanding Voltage 1200VAC V
Termination Type SOLDER
Shell Size 3/B
Body/Shell Style RECEPTACLE
Contact Style RND PIN-SKT
Rated Current (Signal) 7.5A
Body Depth 0.514 inch
Empty Shell NO
Operating Temperature (Min) -65°C
Body Breadth 0.494 inch
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Body Length or Diameter 2.088 inch
Reliability MIL-C-24308
Reference Standard UL
Shell Finish CHROMATE
Terminal Pitch 2.794mm
Total Number of Contacts 25
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Gender Female
Number of Rows 2
Connector Type D SUBMINIATURE CONNECTOR
ECCN Code EAR99
Published 2015
Physical
Shell Material STEEL
Insulation Material GLASS FILLED DIALLYL PHTHALATE
Number of Pins 25
Mount Through Hole
Contact Material NOT SPECIFIED
