DAM15SNMB
RoHS
/
Package /
Category Connectors, Interconnects / D-Sub Connectors
Description
CONN D-SUB RCPT 15POS PNL MNT
PDF
/
Buying Options
Total Price: USD $16.97
Unit Price: USD $16.973911
≥1 USD $16.973911
≥10 USD $16.013121
≥100 USD $15.106731
≥500 USD $14.251622
≥1000 USD $13.444926
Inventory: 4434
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
REACH SVHC Unknown
Technical
Contact Design PREASSEM CONN
Insulator Color GREEN
Contact Pattern STAGGERED
Dielectric Withstanding Voltage 1700VAC V
Shell Size 2/A
Mating Contact Pitch 0.109 inch
Contact Resistance 55mOhm
Contact Style RND PIN-SKT
Rated Current (Signal) 5A
Body Depth 0.186 inch
Empty Shell NO
Body Breadth 0.494 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Number of Contacts 15
Body Length or Diameter 1.541 inch
Reliability COMMERCIAL
Shell Finish CHROMATE
Current Rating 7.5A
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance YES
Contact Finish - Mating NOT SPECIFIED
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Gender Receptacle
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 125°C
Connector Type D-Sub, Receptacle, Signal
ECCN Code EAR99
Termination Solder
Feature Shielded
Published 2013
Packaging Bulk
Physical
Body Material Brass
Housing Material Polyester
Mount Panel
Contact Plating Gold
Contact Material NOT SPECIFIED
