09661556511
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Sub Connectors
Description
D-Sub Standard Connectors DSUB SV FEM SSDP STR29 09P
PDF
/
Buying Options
Total Price: USD $5.17
Unit Price: USD $5.1744
≥1 USD $5.1744
≥10 USD $4.70096
≥100 USD $4.452448
≥500 USD $4.141808
≥1000 USD $3.624078
≥3000 USD $3.520528
Inventory: 237
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Width 6.2mm
Length 31.2mm
Technical
Shell Size, Connector Layout 1 DE E
Contact Form Stamped
Insertion Force-Max 3.336 N
Connector Style D-Sub
Dielectric Withstanding Voltage 1000VAC V
Body/Shell Style PLUG
Flange Feature Housing/Shell (M3)
Insulation Resistance 10000000000Ohm
Contact Resistance 10mOhm
Empty Shell NO
Mating Information MULTIPLE MATING PARTS AVAILABLE
PCB Contact Pattern STAGGERED
Number Of PCB Rows 2
Contact Finish Gold
Reference Standard UL
Shell Finish TIN
Current Rating 6.5A
Depth 12.5mm
Orientation Straight
Total Number of Contacts 9
Pitch 2.74mm
Option GENERAL PURPOSE
Mixed Contacts NO
Contact Type Signal
Filter Feature NO
IEC Conformance NO
DIN Conformance YES
MIL Conformance NO
Subcategory D Type Connectors
Gender Receptacle
Number of Rows 2
Number of Positions 9
Connector Type Receptacle, Female Sockets
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Lock
Packaging Bulk
Operating Temperature -55°C~125°C
Physical
Shell Material, Finish Steel
Housing Material Glass
Dielectric Material Polycyclohexylenedimethylene Terephthalate (PCT), Glass Filled
Mounting Type Through Hole
Mount Through Hole
Contact Material Copper Alloy
Supply Chain
Factory Lead Time 7 Weeks
