3-5178238-0
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN RCPT 80POS .050 R/A GOLD
PDF
/
Buying Options
Total Price: USD $16.87
Unit Price: USD $16.869739
≥1 USD $16.869739
≥10 USD $15.914845
≥100 USD $15.01401
≥500 USD $14.164157
≥1000 USD $13.362417
Inventory: 7639
Minimum: 1
-
+
Technical Details
Compliance
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Dimensions
Panel Thickness 2.01mm
PCB Thickness 2.36mm
Contact Finish Thickness 30.0μin 0.76μm
Length 71.45mm
Technical
Preloaded Yes
Hole Diameter 2.7 mm
Contact Pattern RECTANGULAR
Number of Ports 1
Connector Style Outer Shroud Contacts
Dielectric Withstanding Voltage 500VAC V
Plating Nickel
ELV Compliant
Flange Feature Housing/Shell (M2.6)
Rated Current (Signal) 1A
Empty Shell NO
Lead Length 3.1mm
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Contact Gender FEMALE
Body Breadth 0.37 inch
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
PCB Contact Pattern STAGGERED
Number Of PCB Rows 4
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Depth 11.5mm
Orientation Vertical
Total Number of Contacts 80
Pitch 1.27mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
HTS Code 8536.69.40.30
Number of Rows 2
Color Black
Connector Type Receptacle
ECCN Code EAR99
Termination Solder
Number of Terminations 80
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Feature Board Lock, Latch Lock
JESD-609 Code e3
Series CHAMP .050 II
Published 2011
Physical
Housing Material Thermoplastic
Shell Material Steel
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Through Hole
Contact Plating Tin, Gold
Contact Material PHOSPHOR BRONZE
Supply Chain
Factory Lead Time 17 Weeks
