FX2CA-68P-1.27DSA
RoHS
/
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
Non-RoHS Compliant COMMERCIAL UL STAGGERED BOARD STACKING CONNECTOR Connector UL94V-0 45mOhm 85C 0.5A
PDF
/
Inventory: 6263
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status Non-RoHS Compliant
Dimensions
Length - Termination 0.13 inch
Technical
Contact Pattern RECTANGULAR
PCB Contact Row Spacing 1.905 mm
Dielectric Withstanding Voltage 300VAC V
Termination Type SOLDER
Body/Shell Style RECEPTACLE
Mating Contact Pitch 0.05 inch
Insulation Resistance 1000000000Ohm
Contact Resistance 45mOhm
Rated Current (Signal) 0.5A
Body Depth 0.335 inch
Housing Color Black
UL Flammability Code 94V-0
Operating Temperature (Min) -55°C
Mating Information MULTIPLE MATING PARTS AVAILABLE
Operating Temperature (Max) 85°C
PCB Contact Pattern STAGGERED
Number of Contacts 68
Lead Pitch 1.27mm
Number Of PCB Rows 4
Reliability COMMERCIAL
Reference Standard UL
Reach Compliance Code unknown
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
HTS Code 8536.69.40.40
Additional Feature STAGGERED CONFIGURATION, POLARIZED
Gender Male
Number of Rows 2
Connector Type BOARD STACKING CONNECTOR
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e4
Physical
Mounting Style STRAIGHT
Housing Material Plastic
Mounting Type BOARD
Contact Plating Gold
Contact Material Bronze
