N102A0-52E3PC

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description CONN MINI-D 100POS R/A RECPT
PDF
/
Inventory: 6798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Compliance

Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 30.0μin 0.76μm
Length 84.2mm

Technical

Number of Ports 1
Connector Style Outer Shroud Contacts
Plating Nickel
Max Current Rating 1A
Flange Feature Housing/Shell (4-40); Latchblocks
Housing Color Beige
Contact Finish Gold
Current Rating 1A
Depth 16.7mm
Orientation Right Angle
Pitch 2.54mm
Voltage - Rated 500V
Gender Female
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 100
Connector Type Receptacle
Termination Solder
Number of Terminations 100
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Board Lock, Shielded
Series 102, Mini D Ribbon (MDR)
Published 2000

Physical

Housing Material Polychlorinated
Mounting Type Panel Mount, Through Hole, Right Angle
Mount Panel, Through Hole
Contact Plating Gold

Supply Chain

Factory Lead Time 14 Weeks
