10250-1210PE
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description
CONN RCPT 50POS R/A SOLDER
PDF
/
Buying Options
Total Price: USD $14.13
Unit Price: USD $14.1328
≥1 USD $14.1328
≥10 USD $12.52592
≥100 USD $12.044384
≥500 USD $11.562496
≥1000 USD $10.920184
≥3000 USD $9.956672
Inventory: 148
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Contact Finish Thickness 20.0μin 0.51μm
Length 52.4mm
Technical
Number of Ports 1
Connector Style Outer Shroud Contacts
Dielectric Withstanding Voltage 700VAC V
Max Current Rating 1A
Flange Feature Housing/Shell (M2.6)
Rated Current (Signal) 1A
Empty Shell NO
Housing Color Beige
UL Flammability Code 94V-0
Contact Gender FEMALE
Body Breadth 0.368 inch
Number Of PCB Rows 1
Approval Agency UL
Reliability COMMERCIAL
Contact Finish Gold
Reference Standard UL
Shell Finish NICKEL
Current Rating 1A
Depth 15.15mm
Orientation Right Angle
Total Number of Contacts 50
Pitch 640μm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory D Type Connectors
Additional Feature 3M, SHIELDED
Number of Rows 2
Min Operating Temperature -55°C
Max Operating Temperature 105°C
Number of Positions 50
Connector Type Receptacle
Termination Solder
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Feature Board Guide, Shielded
JESD-609 Code e4
Series 102, Mini D Ribbon (MDR)
Published 2000
Packaging Bulk
Physical
Housing Material Polychlorinated
Shell Material GLASS FILLED PCT
Mounting Type Surface Mount, Right Angle
Mount Surface Mount
Contact Material Copper
Supply Chain
Factory Lead Time 13 Weeks
