10126-900APL

3M
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / D-Shaped Connectors - Centronics
Description CONN PLUG 26POS EDGE MNT SOLDER
PDF
/
Buying Options
Total Price: USD $5.03
Unit Price: USD $5.0336
≥1 USD $5.0336
≥10 USD $4.55488
≥100 USD $4.302848
≥500 USD $4.197952
≥1000 USD $3.987984
≥3000 USD $3.695358
Inventory: 1733
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status RoHS Compliant

Dimensions

Contact Finish Thickness 8.00μin 0.203μm
Length 25.8mm

Technical

Number of Ports 1
Connector Style Center Strip Contacts
Plating Nickel
Max Current Rating 1A
Contact Finish Gold
Current Rating 1A
Depth 16.4mm
Orientation Straight
Pitch 1.27mm
Voltage - Rated 500V
Gender Male
Number of Rows 2
Min Operating Temperature -20°C
Max Operating Temperature 85°C
Number of Positions 26
Connector Type Plug
Termination Solder
Number of Terminations 26
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Shielded
Series 101, Mini D Ribbon (MDR)
Published 2008

Physical

Housing Material Polychlorinated
Shell Material Steel
Mounting Type Board Edge, Straddle Mount
Mount Edge, Straddle Mount
Contact Plating Gold

Supply Chain

Factory Lead Time 10 Weeks
