B82801B0205A100
RoHS
RoHS compliant
RoHS compliantPackage /
Category Transformers / Current Sense Transformers
Description
EPCOS - B82801B0205A100 - Current Sensing Transformer, 1:100, 5.5 ohm, 2 mH, 50 Vμs, 20 A, Surface Mount
PDF
/
Buying Options
Total Price: USD $2.27
Unit Price: USD $2.2704
≥1 USD $2.2704
≥10 USD $1.81544
≥100 USD $1.475232
≥500 USD $1.437216
≥1000 USD $1.399464
≥3000 USD $1.361606
Inventory: 1153
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Physical
Mounting Type Surface Mount
Weight 0.014oz 0.4g
Technical
Packaging Tape & Reel (TR)
Published 2011
Series B82801B
Size / Dimension 0.280Lx0.320W 7.11mmx8.13mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Type Invasive
Termination Style Gull Wing
Inductance 2mH
DC Resistance (DCR) 0.8mOhm Primary 5.5Ohm Secondary
Frequency Range 50kHz~1MHz
Turns Ratio - Primary:Secondary 1:100
Dimensions
Height Seated (Max) 0.200 5.08mm
Compliance
RoHS Status ROHS3 Compliant
