164160-3
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Contacts - Multi Purpose
Description
Pin & Socket Connectors PIN 24-20 AWG TIN
PDF
/
Buying Options
Total Price: USD $1.47
Unit Price: USD $1.4696
≥1 USD $1.4696
≥10 USD $1.34024
≥100 USD $1.30064
≥500 USD $1.287264
≥1000 USD $1.194864
≥3000 USD $1.175046
Inventory: 102843
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Not Applicable
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 13.71mm
Height 2.29mm
Technical
Design Use POWER
Used With CPC CONNECTOR
Cable Entry-Min 0.0433 inch
Cable Entry-Max 0.07 inch
Assembly Item Name CONTACT
Pin or Socket Pin
Insulation Diameter 1.8 mm
Test Current 13A
Contact Termination Crimp
Wire/Cable Gauge 22 AWG
Wire Gauge (Min) 20 AWG
Wire Gauge (Max) 24 AWG
ELV Compliant
Wire Gauge 20-24 AWG
Contact Finish Tin
Depth 2.29mm
Orientation Straight
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
HTS Code 8536.90.40.00
Gender Female
Type Stamped
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series Multimate III+
Published 2004
Packaging Tape & Reel (TR)
Physical
Mount Cable
Contact Material Brass
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Factory Lead Time 18 Weeks
