DSO1-25-0003
RoHS
RoHS compliant
RoHS compliantPackage Radial
Category Filters / Common Mode Chokes
Description
Fixed Inductors DSO Storage choke 3.15A
PDF
/
Inventory: 8991
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 23 Weeks
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case Radial
Terminal Shape WIRE
Weight 13.999987g
Shape/Size Description CYLINDRICAL PACKAGE
Technical
Operating Temperature -40°C~125°C
Packaging Tape & Reel (TR)
Published 2013
Series DSO
Size / Dimension 0.906Lx0.354W 23.00mmx9.00mm
Tolerance 15%
Part Status Active
Moisture Sensitivity Level (MSL) Vendor Undefined
ECCN Code EAR99
HTS Code 8504.50.80.00
Voltage - Rated DC 600V
Shielding NO
Number of Functions 1
Depth 9mm
Construction Toroidal
Military Standard Not
Lead Diameter 0.8 mm
Inductance 100 μH
Max DC Current 3.15A
Inductor Application POWER INDUCTOR
Inductor Type GENERAL PURPOSE INDUCTOR
DC Current 3.15A
Number of Lines 2
DC Resistance (DCR) (Max) 50mOhm
Self Resonant Frequency 20MHz
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
