T8116NLT
RoHS
RoHS compliant
RoHS compliantPackage Horizontal, 4 PC Pad
Category Filters / Common Mode Chokes
Description
Common Mode Chokes Dual 470uH 700mA 300mOhm DCR SMD T/R
PDF
/
Buying Options
Total Price: USD $2.53
Unit Price: USD $2.5344
≥1 USD $2.5344
≥10 USD $2.11816
≥100 USD $1.93424
≥500 USD $1.65792
≥1000 USD $1.51976
≥3000 USD $1.473718
Inventory: 1327
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 11 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Horizontal, 4 PC Pad
Number of Pins 4
Technical
Operating Temperature -40°C~85°C
Packaging Tape & Reel (TR)
Published 2006
Size / Dimension 0.350Lx0.248W 8.90mmx6.30mm
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
ECCN Code EAR99
Additional Feature COMMON MODE CHOKE
Packing Method TAPE AND REEL
Number of Functions 2
Depth 8.9mm
Inductance 470 μH
Current 700mA
Filter Type Signal Line
DC Current 700mA
Number of Lines 2
DC Resistance (DCR) (Max) 300mOhm
Impedance @ Frequency 800Ohm @ 100MHz
Rated Voltage 80V
Inductance @ Frequency 470μH @ 100kHz
Dimensions
Height 4.0894mm
Width 6.3mm
Compliance
RoHS Status RoHS Compliant
