ELF-14M050E
RoHS
/
Package Vertical, 4 PC Pin
Category Filters / Common Mode Chokes
Description
COMMON MODE CHOKE 500MA 2LN TH
PDF
/
Inventory: 6063
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Radiation Hardening No
Dimensions
Height 11.9888mm
Technical
DC Resistance (DCR) (Max) 930mOhm Typ
Number of Lines 2
Current 500mA
Inductance 2.5 mH
Min Operating Temperature -20°C
Max Operating Temperature 115°C
Terminal Finish Tin/Copper (Sn/Cu)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e2
Size / Dimension 0.630Lx0.571W 16.00mmx14.50mm
Series M
Published 2006
Packaging Bulk
Physical
Package / Case Vertical, 4 PC Pin
Mounting Type Through Hole
Mount Through Hole
