B82724J2202N001
RoHS
/
Package /
Category Filters / Common Mode Chokes
Description
Tray DUAL IN-LINE 2 e3 Common Mode Choke 2A 170mOhm 10kHz 31.3mm
PDF
/
Buying Options
Total Price: USD $2.48
Unit Price: USD $2.4816
≥1 USD $2.4816
≥10 USD $2.07856
≥100 USD $1.897632
≥500 USD $1.62646
≥1000 USD $1.59082
Inventory: 866
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status RoHS Compliant
Radiation Hardening No
Dimensions
Length 31.3mm
Height 33.2mm
Technical
DC Current 2A
Inductance-Nom (L) 6800 μH
DC Resistance (DCR) - Parallel 170mOhm
Inductor Type GENERAL PURPOSE INDUCTOR
Lead/Base Style Pin
Terminal Placement DUAL IN-LINE
Inductor Application POWER INDUCTOR
Max DC Current 2A
Test Frequency 10kHz
Inductance 6.8 mH
Lead Diameter 700 μm
Lead Pitch 12.5mm
Military Standard Not
Construction Rectangular
Depth 15mm
Number of Functions 2
Shielding NO
Packing Method Tray
HTS Code 8504.50.80.00
Min Operating Temperature -40°C
Max Operating Temperature 125°C
ECCN Code EAR99
Number of Terminations 4
Pbfree Code yes
JESD-609 Code e3
Tolerance 30%
Physical
Shape/Size Description RECTANGULAR PACKAGE
Material - Core Ferrite
Terminal Shape WIRE
Mount Radial
Contact Plating Tin
Supply Chain
Lifecycle Status PRODUCTION (Last Updated: 1 month ago)
