228217-1
RoHS
/
Package SMB
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Conn SMB RCP 50Ohm Crimp ST Panel Mount Gold
PDF
/
Inventory: 4764
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Contact Plating Gold
Mount Bulkhead
Package / Case SMB
Insulation Material Polytetrafluoroethylene
Dielectric Material PTFE
Body Material Brass
Technical
Packaging Carton
Pbfree Code no
Termination Crimp
Max Operating Temperature 85°C
Min Operating Temperature -65°C
Gender Male
Voltage - Rated 400V
Fastening Type Snap
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Option GENERAL PURPOSE
Orientation Straight
Depth 6.35mm
Frequency 4GHz
Number of Contacts 1
Housing Color Silver
Polarity Normal, Standard
Insulation Resistance 1GOhm
Body/Shell Style JACK
ELV Non-Compliant
Impedance 50Ohm
Sealable No
Frequency (Max) 4GHz
Plating - Body Nickel
Insertion Loss 0.3 dB
Dimensions
Length 23.36mm
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
