0734153410
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
Conn MMCX F 50Ohm ST Cable Mount Gold Bag
PDF
/
Inventory: 7046
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Shield Termination Crimp
Cable Group 1.13mm Coaxial Cable
Includes 3 pcs - 1 Connector, 1 Contact, 1 Ferrule
Contact Termination Solder
Mating Cycles 500
Frequency (Max) 6GHz
Number of Ports 1
Connector Style MMCX
Impedance 50Ohm
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Contact Finish - Mating NOT SPECIFIED
Fastening Type Snap-On
Voltage - Rated 170V
Connector Type Jack, Female Socket
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series 73415
Packaging Bulk
Operating Temperature -55°C~165°C
Physical
Panel Mount NO
Center Contact Material Beryllium Copper
Center Contact Plating Gold
Body Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Mounting Type Free Hanging (In-Line)
Supply Chain
Factory Lead Time 10 Weeks
