FA2-NASJ-C01-6
RoHS
RoHS compliant
RoHS compliantPackage SMB
Category Connectors, Interconnects / Coaxial Connectors (RF)
Description
RF Connectors / Coaxial Connectors RG174 188 316 SMB FEMALE ST FAKRA
PDF
/
Inventory: 6798
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Contact Material Copper
Contact Plating Gold
Mount Free Hanging
Mounting Type Free Hanging (In-Line)
Package / Case SMB
Insulation Material Teflon
Dielectric Material Polytetrafluoroethylene (PTFE)
Housing Material Polyester
Body Material Brass
Center Contact Plating Gold
Center Contact Material Beryllium Copper
Technical
Operating Temperature -40°C~100°C
Packaging Bulk
Published 2001
Feature Code A
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Termination Crimp
Connector Type Jack, Female Socket
Max Operating Temperature 100°C
Min Operating Temperature -40°C
Color Black
Fastening Type Latch Lock
Orientation Straight
Housing Color Black, Jet
Polarity Standard
Plating Brass
Impedance 50Ohm
Connector Style SMB, Fakra
Number of Ports 2
Body Plating Nickel
Frequency (Max) 4GHz
Mating Cycles 100
Contact Termination Crimp
Includes 9 pcs - 2 Connectors, 2 Contacts, 2 Ferrules, 1 Housing, 2 Locking Clips
Insertion Loss 0.3dB
Body Finish Nickel
Cable Group RG-174, 188, 188A, 316, LMR-100, M17/119-RG174
Shield Termination Crimp
Compliance
RoHS Status RoHS Compliant
Lead Free Lead Free
