6705
RoHS
/
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF) - Adapters
Description
CONN ADAPT JACK-JACK BNC 75 OHM
PDF
/
Buying Options
Total Price: USD $21.55
Unit Price: USD $21.5512
≥1 USD $21.5512
≥10 USD $20.724
Inventory: 58
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Technical
Adapter Series BNC to BNC
Gender Type A Female
Center Gender Female to Female
Adapter Type Jack to Jack
Conversion Type Same Series
VSWR 1.3
Convert To (Adapter End) BNC Jack, Female Socket
Convert From (Adapter End) BNC Jack, Female Socket
Body Finish Black Nickel
Insertion Loss 0.2 dB
Includes 3 pcs - 1 Connector, 1 Lockwasher, 1 Nut
Mating Cycles 500
Body Plating Nickel
Impedance 75Ohm
Frequency 3GHz
Reach Compliance Code unknown
Style Straight
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Bayonet Lock, Bayonet Lock
HTS Code 8536.69.80.00
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
Feature Isolated
JESD-609 Code e4
Packaging Bulk
Operating Temperature -40°C~85°C
Physical
Center Contact Plating Gold
Housing Material Brass
Dielectric Material Polytetrafluoroethylene (PTFE)
Insulation Material Teflon
Mounting Feature Bulkhead
Mounting Type Panel Mount
Mount Bulkhead, Panel
Contact Material BERYLLIUM COPPER
Supply Chain
Factory Lead Time 2 Weeks
