3285 image
Favorite
3285 image
Favorite
RoHS
RoHS RoHS compliant
Package /
Category Connectors, Interconnects / Coaxial Connectors (RF) - Adapters
Description CONN ADAPT PLUG TO JACK BNC
PDF
/
Buying Options
Total Price: USD $1.72
Unit Price: USD $1.716
≥1 USD $1.716
Inventory: 84
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Dimensions

Width 76.2mm
Length 33mm
Height 6.35mm

Technical

Gender Type B Male
Adapter Series BNC to BNC, Dual
Gender Type A Female
Center Gender Female to Male
Adapter Type Plug to Jack
Conversion Type Same Series
Convert To (Adapter End) BNC Jack, Female Socket (2)
Convert From (Adapter End) BNC Plug, Male Pin
Operating Frequency-Max 4GHz
Impedance 50Ohm
Plating Nickel
Polarity Normal
Style T-Shape
Orientation Tee Style
Option GENERAL PURPOSE
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Bayonet Lock, Bayonet Lock
HTS Code 8536.69.80.00
Additional Feature SHIELDED
Voltage - Rated 500V
Resistance 50Ohm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Published 2002
Packaging Bulk
Operating Temperature -65°C~165°C

Physical

Center Contact Material Beryllium Copper; Brass
Center Contact Plating Gold
Body Material Brass
Weight 23.677522g
Dielectric Material Polytetrafluoroethylene (PTFE)
Insulation Material Polytetrafluoroethylene
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Brass, Copper

Supply Chain

Factory Lead Time 2 Weeks
