DS1685E-5+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 24-TSSOP (0.173, 4.40mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Real Time Clocks
Description 24-TSSOP (0.173 4.40mm Width) DS1685 8473.30.11.80 Alarm NVSRAM Square Wave Output Y2K rtc clock circuit 4.5V~5.5V 3mA @ 5V 7.8mm 0.032MHz
PDF
/
Buying Options
Total Price: USD $8.14
Unit Price: USD $8.14
≥1 USD $8.14
≥10 USD $7.3568
≥100 USD $7.014876
≥500 USD $6.090946
≥1000 USD $5.817196
≥3000 USD $5.30391
Inventory: 16
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mount Surface Mount
Mounting Type Surface Mount
Package / Case 24-TSSOP (0.173, 4.40mm Width)
Number of Pins 24

Technical

Operating Temperature 0°C~70°C
Packaging Tube
Published 2000
JESD-609 Code e3
Feature Alarm, NVSRAM, Square Wave Output, Y2K
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 24
ECCN Code EAR99
Type Clock/Calendar
Terminal Finish Matte Tin (Sn)
HTS Code 8473.30.11.80
Subcategory Timer or RTC
Technology CMOS
Voltage - Supply 4.5V~5.5V
Terminal Position DUAL
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Terminal Pitch 0.65mm
Base Part Number DS1685
Pin Count 24
Operating Supply Voltage 5V
Power Supplies 5V
Interface Parallel
Memory Size 242B
Clock Frequency 0.032MHz
Logic Function Clock
External Data Bus Width 8
Number of Timers 1
Time Format HH:MM:SS (12/24 hr)
Date Format YY-MM-DD-dd
Current - Timekeeping (Max) 3mA @ 5V
Time-Min SECONDS
Interrupt Capability Y
Voltage - Supply, Battery 2.5V~3.7V
Volatile YES

Dimensions

Height Seated (Max) 1.1mm
Length 7.8mm
Width 4.4mm

Compliance

Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
