DS1100Z-125
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Nonprogrammable TIN LEAD delay line IC -40C~85C 5V 25ns 4.9mm
PDF
/
Inventory: 7121
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature -40°C~85°C
Packaging Tube
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish TIN LEAD
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 245
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G8
Function Nonprogrammable
Qualification Status COMMERCIAL
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 25ns
Programmable Delay Line NO
Available Total Delays 125ns
Total Delay-Nom (td) 125 ns
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status Non-RoHS Compliant
