DS1100M-75
RoHS
/
Package 8-DIP (0.300, 7.62mm)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE Nonprogrammable TIN LEAD CMOS delay line IC -40C~85C 5V 15ns 7.62mm
PDF
/
Buying Options
Total Price: USD $4.05
Unit Price: USD $4.0451
≥1 USD $4.0451
≥10 USD $3.3193
≥100 USD $3.2148
≥500 USD $3.11125
≥1000 USD $3.0077
Inventory: 1552
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Surface Mount NO
Package / Case 8-DIP (0.300, 7.62mm)
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 7.62mm
Technical
Total Delay-Nom (td) 75 ns
Available Total Delays 75ns
Programmable Delay Line NO
Delay to 1st Tap 15ns
Number of Independent Delays 1
Number of Taps/Steps 5
Output Impedance 50Ohm
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Qualification Status COMMERCIAL
Function Nonprogrammable
JESD-30 Code R-PDIP-T8
Time@Peak Reflow Temperature-Max (s) 20
Supply Voltage 5V
Peak Reflow Temperature (Cel) 240
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature -40°C~85°C
