DS1040Z-B40
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
PULSE GENERATOR DELAY LINE GULL WING 1-Shot Programmable TIN LEAD delay line IC 0C~70C 5V 20ns 4.9mm
PDF
/
Inventory: 6591
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.9mm
Length 4.9mm
Technical
Tap Increment 5ns
Available Total Delays 40ns
Programmable Delay Line YES
Delay to 1st Tap 20ns
Number of Independent Delays 1
Number of Taps/Steps 5
Logic IC Type PULSE GENERATOR DELAY LINE
Output Polarity COMPLEMENTARY
Family CMOS/TTL
Qualification Status COMMERCIAL
Function 1-Shot, Programmable
JESD-30 Code R-PDSO-G8
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Supply Voltage 5V
Peak Reflow Temperature (Cel) 245
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.75V~5.25V
Technology CMOS
Terminal Finish TIN LEAD
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
