DS1033Z-30
RoHS
/
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
SILICON DELAY LINE GULL WING Multiple NOT SPECIFIED delay line IC 2.7V 30ns 4.9mm
PDF
/
Inventory: 3344
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Packaging Tube
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish NOT SPECIFIED
Voltage - Supply 3.3V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) NOT SPECIFIED
Supply Voltage 3.3V
Terminal Pitch 1.27mm
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
JESD-30 Code R-PDSO-G8
Function Multiple
Qualification Status COMMERCIAL
Operating Temperature (Max) 70°C
Temperature Grade COMMERCIAL
Supply Voltage-Min (Vsup) 2.7V
Family 1000
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Number of Taps/Steps 1
Number of Independent Delays 3
Delay to 1st Tap 30ns
Programmable Delay Line NO
Available Total Delays 30, 30, 30ns
Total Delay-Nom (td) 30 ns
Dimensions
Height Seated (Max) 1.75mm
Length 4.9mm
Compliance
RoHS Status Non-RoHS Compliant
