ATSAMA5D28C-LD1G-CUR
RoHS
/
Package 289-LFBGA
Category Integrated Circuits (ICs) / Embedded - Microprocessors
Description
CORTEX-A5 MPU 1GBIT LPDDR2 BGA I
PDF
/
Inventory: 8014
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Package / Case 289-LFBGA
Surface Mount YES
Technical
Operating Temperature -40°C~85°C TA
Packaging Tape & Reel (TR)
Series SAMA5D2
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 361
Technology CMOS
Terminal Position BOTTOM
Terminal Form BALL
Supply Voltage 1.2V
Terminal Pitch 0.8mm
Reach Compliance Code compliant
Base Part Number ATSAMA5D28
JESD-30 Code S-PBGA-G361
Supply Voltage-Max (Vsup) 1.3V
Supply Voltage-Min (Vsup) 1.14V
Speed 500MHz
uPs/uCs/Peripheral ICs Type MICROPROCESSOR, RISC
Core Processor ARM? Cortex?-A5
Clock Frequency 24MHz
Bit Size 32
Boundary Scan YES
Low Power Mode YES
Format FLOATING POINT
Integrated Cache YES
RAM (words) 32768
Voltage - I/O 3.3V
Ethernet 10/100Mbps (1)
Number of Cores/Bus Width 1 Core 32-Bit
Graphics Acceleration Yes
RAM Controllers LPDDR1, LPDDR2, LPDDR3, DDR2, DDR3, DDR3L, QSPI
USB USB 2.0 + HSIC
Additional Interfaces I2C, SMC, SPI, UART, USART, QSPI
Number of Serial I/Os 10
Co-Processors/DSP Multimedia; NEON? MPE
On Chip Data RAM Width 32
Security Features ARM TZ, Boot Security, Cryptography, RTIC, Secure Fusebox, Secure JTAG, Secure Memory, Secure RTC
Display & Interface Controllers Keyboard, LCD, Touchscreen
Number of DMA Channels 51
Dimensions
Height Seated (Max) 1.2mm
Length 16mm
