DS1100Z-40+

Maxim Integrated
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description SILICON DELAY LINE GULL WING Nonprogrammable Matte Tin (Sn) delay line IC -40C~85C 6Weeks 5V 8ns
PDF
/
Buying Options
Total Price: USD $4.5
Unit Price: USD $4.503247
≥1 USD $4.503247
≥200 USD $1.743531
≥500 USD $1.681825
≥1000 USD $1.651628
Inventory: 1464
Minimum: 1
-
+

Technical Details

Supply Chain

Factory Lead Time 6 Weeks

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Number of Pins 8

Technical

Operating Temperature -40°C~85°C
Packaging Tube
Published 2011
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1100
Function Nonprogrammable
Qualification Status Not Qualified
Power Supplies 5V
Output Polarity TRUE
Logic IC Type SILICON DELAY LINE
Prop. Delay@Nom-Sup 40 ns
Output Impedance 50Ohm
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 8ns
Programmable Delay Line NO
Available Total Delays 40ns
Total Delay-Nom (td) 40 ns

Dimensions

Length 4.9mm
Width 3.9mm

Compliance

RoHS Status ROHS3 Compliant
Lead Free Lead Free
