DS1100LU-125+
RoHS
RoHS compliant
RoHS compliantPackage 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
Surface Mount SILICON DELAY LINE GULL WING Nonprogrammable delay line IC -40C~85C 6Weeks 3V 25ns
PDF
/
Buying Options
Total Price: USD $9.24
Unit Price: USD $9.24
≥1 USD $9.24
≥10 USD $8.35032
≥100 USD $7.96224
≥500 USD $6.913632
≥1000 USD $6.602886
≥3000 USD $6.020291
Inventory: 61
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 3mm
Length 3mm
Technical
Total Delay-Nom (td) 125 ns
Available Total Delays 125ns
Programmable Delay Line NO
Delay to 1st Tap 25ns
Number of Independent Delays 1
Number of Taps/Steps 5
Output Impedance 50Ohm
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Qualification Status Not Qualified
Function Nonprogrammable
Base Part Number DS1100L
Time@Peak Reflow Temperature-Max (s) 30
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3V~3.6V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2015
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
