DS1040Z-D60+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description
PULSE GENERATOR DELAY LINE GULL WING 1-Shot Programmable Tin (Sn) delay line IC 0C~70C 2002 5V 20ns
PDF
/
Inventory: 4135
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 8-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~70°C
Packaging Tube
Published 2002
JESD-609 Code e3
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 8
Terminal Finish Tin (Sn)
Subcategory Delay Lines
Technology CMOS
Voltage - Supply 4.75V~5.25V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 5V
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DS1040
JESD-30 Code R-PDSO-G8
Function 1-Shot, Programmable
Qualification Status Not Qualified
Power Supplies 5V
Family CMOS/TTL
Output Polarity COMPLEMENTARY
Logic IC Type PULSE GENERATOR DELAY LINE
Number of Taps/Steps 5
Number of Independent Delays 1
Delay to 1st Tap 20ns
Programmable Delay Line YES
Available Total Delays 60ns
Tap Increment 10ns
Dimensions
Length 4.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
