LTC6994CS6-1#TRMPBF image
Favorite
LTC6994CS6-1#TRMPBF image
Favorite
RoHS
RoHS RoHS compliant
Package SOT-23-6 Thin, TSOT-23-6
Category Integrated Circuits (ICs) / Clock/Timing - Delay Lines
Description SILICON DELAY LINE GULL WING Programmable Matte Tin (Sn) delay line IC 0C~70C 0.2mA 8Weeks 2.25V
PDF
/
Buying Options
Total Price: USD $4.05
Unit Price: USD $4.048
≥1 USD $4.048
≥10 USD $3.6388
≥100 USD $3.439744
≥500 USD $2.981
≥1000 USD $2.828179
Inventory: 893
Minimum: 1
-
+

Technical Details

Compliance

RoHS Status ROHS3 Compliant

Dimensions

Length 2.9mm

Technical

Available Total Delays 1μs ~ 33.6s
Programmable Delay Line YES
Number of Independent Delays 1
Number of Taps/Steps 8
Power Supply Current-Max (ICC) 0.2mA
Logic IC Type SILICON DELAY LINE
Output Polarity TRUE
Supply Voltage-Min (Vsup) 2.25V
Power Supplies 2.5/5V
Supply Voltage-Max (Vsup) 5.5V
Qualification Status Not Qualified
Function Programmable
JESD-30 Code R-PDSO-G6
Base Part Number LTC6994
Time@Peak Reflow Temperature-Max (s) 30
Terminal Pitch 0.95mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 2.25V~5.5V
Technology CMOS
Subcategory Delay Lines
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
JESD-609 Code e3
Series TimerBlox?
Published 2007
Packaging Tape & Reel (TR)
Operating Temperature 0°C~70°C

Physical

Surface Mount YES
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting Type Surface Mount

Supply Chain

Factory Lead Time 8 Weeks
