ICS180M-53LFT image
Favorite
ICS180M-53LFT image
Favorite
RoHS
/
Package SOIC
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description Clock SOIC ALSO OPERATE AT 5V SUPPLY e3 clock generator ic 3.465V 28MHz 50mA 4.9mm
PDF
/
Inventory: 4667
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and contact information to get a quote.
Quotation Consultation
Is there anything else we can help you solve?
Inquiry

Technical Details

Physical

Mount Surface Mount
Package / Case SOIC

Technical

Packaging Tape & Reel (TR)
Published 2004
JESD-609 Code e3
Pbfree Code yes
Moisture Sensitivity Level (MSL) 1
Number of Terminations 8
ECCN Code EAR99
Terminal Finish Matte Tin (Sn) - annealed
Max Operating Temperature 70°C
Min Operating Temperature 0°C
Additional Feature ALSO OPERATE AT 5V SUPPLY
Technology CMOS
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Supply Voltage 3.3V
Time@Peak Reflow Temperature-Max (s) 30
Pin Count 8
JESD-30 Code R-PDSO-G8
Qualification Status Not Qualified
Supply Voltage-Max (Vsup) 3.465V
Power Supplies 3.3/5V
Temperature Grade COMMERCIAL
Number of Circuits 1
Supply Current-Max 50mA
Frequency (Max) 28MHz
Input Clock
Primary Clock/Crystal Frequency-Nom 28MHz
PLL Yes

Dimensions

Length 4.9mm
Width 3.9mm

Compliance

RoHS Status RoHS Compliant
