W134SH
RoHS
/
Package 24-SSOP (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Generators, PLLs, Frequency Synthesizers
Description
Clock Clock/Frequency Generator 24-SSOP (0.154 3.90mm Width) W134 clock generator ic 3.3V 400MHz 8.69mm 0C~70C
PDF
/
Buying Options
Total Price: USD $1.63
Unit Price: USD $1.628
≥1 USD $1.628
Inventory: 833
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
Dimensions
Width 3.94mm
Length 8.69mm
Technical
Divider/Multiplier Yes/Yes
Differential - Input:Output No/Yes
PLL Yes
Primary Clock/Crystal Frequency-Nom 100MHz
Ratio - Input:Output 1:1
Input Clock
Number of Circuits 1
Power Supplies 3.3V
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G24
Pin Count 24
Output RSL
Base Part Number W134
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 400MHz
Reach Compliance Code not_compliant
Terminal Pitch 0.635mm
Supply Voltage 3.3V
Peak Reflow Temperature (Cel) 220
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 3.135V~3.465V
Technology CMOS
Terminal Finish TIN LEAD
Type Clock/Frequency Generator
ECCN Code EAR99
Number of Terminations 24
Moisture Sensitivity Level (MSL) 2 (1 Year)
Part Status Obsolete
JESD-609 Code e0
Published 2002
Packaging Tube
Operating Temperature 0°C~70°C
Physical
Package / Case 24-SSOP (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
