LMK00306SQ/NOPB
RoHS
RoHS compliant
RoHS compliantPackage 36-WFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
CML HCSL HSTL LVDS LVPECL SSTL Crystal LMK00306 36-WFQFN Exposed Pad ACTIVE (Last Updated: 4days ago) clock driver 6mm 13.5mA 0.05ns 3.1GHz
PDF
/
Buying Options
Total Price: USD $8.41
Unit Price: USD $8.4128
≥1 USD $8.4128
≥10 USD $7.59792
≥100 USD $7.244512
≥500 USD $6.290328
≥1000 USD $6.007584
≥3000 USD $5.47749
Inventory: 1154
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 36-WFQFN Exposed Pad
Number of Pins 36
Technical
Operating Temperature -40°C~85°C
Packaging Cut Tape (CT)
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Number of Terminations 36
ECCN Code EAR99
Type Fanout Buffer (Distribution), Multiplexer, Translator
Terminal Finish Matte Tin (Sn)
Subcategory Clock Drivers
Packing Method TR
Voltage - Supply 3.15V~3.45V
Terminal Position QUAD
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Supply Voltage 3.3V
Terminal Pitch 0.5mm
Base Part Number LMK00306
Output HCSL, LVCMOS, LVDS, LVPECL
Pin Count 36
Number of Outputs 7
Supply Voltage-Max (Vsup) 3.45V
Power Supplies 2.5/3.33.3V
Number of Circuits 1
Load Capacitance 5pF
Nominal Supply Current 13.5mA
Propagation Delay 1.55 ns
Frequency (Max) 3.1GHz
Input CML, HCSL, HSTL, LVDS, LVPECL, SSTL, Crystal
Ratio - Input:Output 3:7
Differential - Input:Output Yes/Yes
Same Edge Skew-Max (tskwd) 0.05 ns
Dimensions
Height Seated (Max) 0.8mm
Length 6mm
Width 6mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
