CDCLVP1208RHDR
RoHS
RoHS compliant
RoHS compliantPackage 28-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
LVCMOS LVDS LVPECL LVTTL CDCLVP1208 28-VFQFN Exposed Pad ACTIVE (Last Updated: 6days ago) clock driver 5mm 2.5/3.3V 0.02ns 2GHz
PDF
/
Buying Options
Total Price: USD $8.6
Unit Price: USD $8.5976
≥1 USD $8.5976
≥10 USD $7.76952
≥100 USD $7.408544
≥500 USD $6.432712
≥1000 USD $6.143562
≥3000 USD $5.601482
Inventory: 1005
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Thickness 900μm
Width 5mm
Length 5mm
Height 1mm
Technical
Same Edge Skew-Max (tskwd) 0.02 ns
fmax-Min 2000 MHz
Power Supply Current-Max (ICC) 73mA
Prop. Delay@Nom-Sup 0.45 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 2:8
Input LVCMOS, LVDS, LVPECL, LVTTL
Family CDC
Frequency (Max) 2GHz
Turn On Delay Time 450 ps
Propagation Delay 450 ps
Number of Circuits 1
Supply Voltage-Min (Vsup) 2.375V
Power Supplies 2.5/3.3V
Supply Voltage-Max (Vsup) 3.6V
Number of Outputs 8
Pin Count 28
Output LVPECL
Base Part Number CDCLVP1208
Supply Voltage 2.5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Position QUAD
Voltage - Supply 2.375V~3.6V
Packing Method TR
Subcategory Clock Drivers
Type Fanout Buffer (Distribution), Multiplexer
Number of Terminations 28
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Pbfree Code yes
JESD-609 Code e4
Packaging Tape & Reel (TR)
Operating Temperature -40°C~85°C
Physical
Number of Pins 28
Package / Case 28-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Contact Plating Gold
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 6 days ago)
Factory Lead Time 6 Weeks
