100315SC
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
Clock 16-SOIC (0.154 3.90mm Width) Obsolete MATTE TIN clock driver 3.9mm 4.2V~5.7V 0.05ns 750MHz
PDF
/
Buying Options
Total Price: USD $4.75
Unit Price: USD $4.752
≥1 USD $4.752
Inventory: 1103
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Surface Mount
Package / Case 16-SOIC (0.154, 3.90mm Width)
Surface Mount YES
Technical
Operating Temperature 0°C~85°C
Packaging Tube
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 16
Type Fanout Buffer (Distribution)
Terminal Finish MATTE TIN
Technology ECL
Voltage - Supply 4.2V~5.7V
Terminal Position DUAL
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Number of Functions 4
Reach Compliance Code unknown
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 16
Qualification Status Not Qualified
Number of Circuits 1
Frequency (Max) 750MHz
Input Clock
Ratio - Input:Output 1:4
Differential - Input:Output Yes/Yes
fmax-Min 750 MHz
Same Edge Skew-Max (tskwd) 0.05 ns
Number of True Outputs 4
Dimensions
Length 9.9mm
Width 3.9mm
Compliance
RoHS Status ROHS3 Compliant
