MC10EL11DTG
RoHS
/
Package 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
10EL DUAL Surface Mount ECL Clock Fanout Buffer (Distribution) IC -40C~85C 1.5GHz 0.02ns 50mA
PDF
/
Buying Options
Total Price: USD $45.48
Unit Price: USD $45.475108
≥1 USD $45.475108
≥10 USD $42.901044
≥100 USD $40.472683
≥500 USD $38.181777
≥1000 USD $36.020543
Inventory: 1162
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
REACH SVHC No SVHC
Dimensions
Width 3.1mm
Length 3.1mm
Height 950μm
Technical
Schmitt Trigger Input No
Same Edge Skew-Max (tskwd) 0.02 ns
High Level Output Current 50mA
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:2
Input ECL, PECL
Halogen Free Halogen Free
Logic Function Buffer
Turn On Delay Time 385 ps
Propagation Delay 385 ps
Nominal Supply Current 26mA
Number of Circuits 1
Power Supplies -5.2V
Supply Voltage-Max (Vsup) 5.7V
Number of Outputs 4
Pin Count 8
Output ECL, PECL
Base Part Number MC10EL11
Time@Peak Reflow Temperature-Max (s) 40
Frequency 1.5GHz
Terminal Pitch 0.65mm
Supply Voltage 5V
Number of Functions 1
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Voltage - Supply 4.2V~5.7V
Technology ECL
Subcategory Clock Drivers
Terminal Finish Tin (Sn)
Type Fanout Buffer (Distribution)
Number of Terminations 8
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series 10EL
Published 2008
Packaging Tube
Operating Temperature -40°C~85°C
Physical
Number of Pins 8
Package / Case 8-TSSOP, 8-MSOP (0.118, 3.00mm Width)
Mounting Type Surface Mount
Mount Surface Mount
