MC100EP809MNG
RoHS
RoHS compliant
RoHS compliantPackage 32-VFQFN Exposed Pad
Category Integrated Circuits (ICs) / Clock/Timing - Clock Buffers, Drivers
Description
HSTL LVDS LVPECL MC100EP809 32-VFQFN Exposed Pad ACTIVE (Last Updated: 4days ago) clock buffer 5mm 95mA 0.05ns 750MHz
PDF
/
Buying Options
Total Price: USD $12.53
Unit Price: USD $12.5312
≥1 USD $12.5312
≥10 USD $11.52008
≥100 USD $11.042926
≥500 USD $9.729764
≥1000 USD $9.252223
≥3000 USD $8.65531
Inventory: 152
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 5mm
Length 5mm
Height Seated (Max) 1mm
Technical
Same Edge Skew-Max (tskwd) 0.05 ns
fmax-Min 500 MHz
Propagation Delay (tpd) 1 ns
Prop. Delay@Nom-Sup 1.11 ns
Differential - Input:Output Yes/Yes
Ratio - Input:Output 1:9
Input HSTL, LVDS, LVPECL
Halogen Free Halogen Free
Frequency (Max) 750MHz
Nominal Supply Current 95mA
Number of Circuits 2
Supply Voltage-Min (Vsup) 3V
Supply Voltage-Max (Vsup) 3.6V
Operating Supply Voltage 3.3V
Pin Count 32
Output HSTL
Base Part Number MC100EP809
Terminal Pitch 0.5mm
Supply Voltage 3.3V
Number of Functions 1
Terminal Position QUAD
Voltage - Supply 3V~3.6V
Technology ECL
Subcategory Clock Drivers
Terminal Finish Tin (Sn)
Type Fanout Buffer (Distribution), Multiplexer
Number of Terminations 32
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series 100EP
Published 2006
Packaging Tube
Operating Temperature 0°C~85°C
Physical
Number of Pins 32
Package / Case 32-VFQFN Exposed Pad
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Factory Lead Time 20 Weeks
