796433-1
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Standard Circular Connector CPC POSTED RCPT 13-7
PDF
/
Inventory: 3415
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
Flammability Rating UL94 V-0
RoHS Status RoHS Compliant
Technical
VDE Tested No
Number of Ports 1
Plating Gold, Plastic
Shell Size 13
ELV Non-Compliant
Backshell Type SOLID
Empty Shell NO
Lead Length 5.59mm
Contact Gender FEMALE
Current Rating 13A
Orientation Straight
Total Number of Contacts 7
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Fastening Type Threaded
Additional Feature POLARIZED
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Connector, Pin, Receptacle
Termination Through Hole
Number of Terminations 7
Pbfree Code no
JESD-609 Code e0
Physical
Housing Material Nylon
Shell Material POLYAMIDE
Insulation Material Plastic
Mount Flanges, Panel
Contact Plating Gold
Contact Material COPPER ALLOY
