796387-1
RoHS
/
Package /
Category Connectors, Interconnects / Circular Connectors
Description
Standard Circular Connector CPC POSTED RCPT 23-24 R/A
PDF
/
Inventory: 8561
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass
Contact Plating Lead, Tin
Mount Flanges, Panel, Through Hole
Insulation Material Plastic
Shell Material POLYETHYLENE
Housing Material Thermoplastic
Technical
JESD-609 Code e0
Pbfree Code no
Termination Solder
ECCN Code EAR99
Connector Type Receptacle
Max Operating Temperature 105°C
Min Operating Temperature -40°C
Color Black
HTS Code 8536.69.40.20
Fastening Type Threaded
Contact Finish - Mating TIN LEAD OVER NICKEL
MIL Conformance NO
DIN Conformance NO
IEC Conformance NO
Filter Feature NO
Mixed Contacts NO
Option GENERAL PURPOSE
Orientation Right Angle
Depth 61.72mm
Current Rating 13A
Number of Contacts 24
Contact Gender FEMALE
Empty Shell NO
Backshell Type SOLID
ELV Non-Compliant
Shell Size 23
Dimensions
Length 44.45mm
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Flammability Rating UL94 V-0
Lead Free Contains Lead
