PHL.1K.308.CLAC45
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 8P FREE RCPT SOLDER CABLE COLLET 4.5MM
PDF
/
Inventory: 2371
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings Dust Tight, IP66, Water Resistant, Waterproof
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 39.4μin 1.00μm
Technical
Cable Opening 0.161 ~ 0.177 (4.10mm ~ 4.50mm)
Shell Size - Insert 308
Shell Finish Chrome
Current Rating 5A
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Shielding Shielded
Orientation L
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 8
Connector Type Receptacle, Male Pins
Termination Solder Cup
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Feature Backshell
Series 1K
Packaging Bulk
Operating Temperature -55°C~200°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
