PHG.2B.306.CLLD72Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors 6P SOLDER SCKT RECPT CABLE COLLET 7.2MM
PDF
/
Inventory: 1538
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 46mm
Diameter 16.5mm
Technical
Cable Opening 0.244 ~ 0.283 (6.20mm ~ 7.20mm)
Contact Style Socket
Shell Size - Insert 306
Shell Finish Chrome
Current Rating 12A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation G
Contact Finish - Mating Gold
Fastening Type Push-Pull
Gender Female
Color Silver
Number of Positions 6
Connector Type Receptacle, Female Sockets
Termination Solder Cup
Part Status Active
Feature Backshell
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
