FGJ.2B.302.CLLD92Z
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
Circular Push Pull Connectors PLUG CDJ 2CTS C-COL
PDF
/
Buying Options
Total Price: USD $50.86
Unit Price: USD $50.8552
≥1 USD $50.8552
≥10 USD $46.6708
≥100 USD $44.875424
≥500 USD $43.3796
≥1000 USD $40.986264
Inventory: 49
Minimum: 1
-
+
Technical Details
Compliance
Ratings IP50
RoHS Status ROHS3 Compliant
Material Flammability Rating UL94 V-0
Dimensions
Contact Finish Thickness - Mating 59.0μin 1.50μm
Length 50mm
Diameter 15mm
Technical
Cable Opening 0.323 ~ 0.362 (8.20mm ~ 9.20mm)
Contact Style Socket
Contact Gender Female
Shell Size - Insert 302
Shell Finish Chrome
Current Rating 25A
Ingress Protection IP50 - Dust Protected
Shielding Shielded
Orientation J
Contact Finish - Mating Gold
Fastening Type Push-Pull
Color Silver
Number of Positions 2
Connector Type Plug, Female Sockets
ECCN Code EAR99
Termination Solder Cup
Part Status Active
Pbfree Code yes
Feature Backshell
Series 2B
Packaging Bulk
Operating Temperature -55°C~250°C
Physical
Backshell Material, Plating Brass, Chrome
Insert Material Polyetheretherketone (PEEK)
Shell Material Brass
Mounting Type Free Hanging (In-Line)
Mount Free Hanging
Contact Material Bronze
