ERA.3E.303.CLL
RoHS
RoHS compliant
RoHS compliantPackage /
Category Connectors, Interconnects / Circular Connectors
Description
CONN CIRC RCPT 3POS SOLDER CUP
PDF
/
Inventory: 8143
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Contact Material Brass, Bronze
Contact Plating Copper, Gold, Nickel
Mount Bulkhead, Panel, Rear Side Nut
Mounting Type Panel Mount
Mounting Feature Bulkhead - Rear Side Nut
Shell Material Brass
Insert Material Polyetheretherketone (PEEK)
Technical
Operating Temperature -55°C~200°C
Packaging Bulk
Series 3E
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) Not Applicable
Termination Solder Cup
Connector Type Receptacle, Female Sockets and Male Pins
Number of Positions 3
Color Silver
Fastening Type Push-Pull
Voltage - Rated DC 2.1kV
Contact Finish - Mating Gold
Orientation Keyed
Shielding Shielded
Ingress Protection IP66/68 - Dust Tight, Water Resistant, Waterproof
Current Rating 20A
Shell Finish Chrome
Shell Size - Insert 303
Voltage - Rated AC 1.5kV
Contact Gender Male
Wire Gauge (Max) 14 AWG
Wire Gauge (Min) 16 AWG
Compliance
Material Flammability Rating UL94 V-0
RoHS Status ROHS3 Compliant
Ratings Dust Tight, IP66, IP68, Water Resistant, Waterproof
