74099-1007
RoHS
/
Package /
Category Connectors, Interconnects / Rectangular Connectors - Headers, Male Pins
Description
Conn Shrouded Header (4 Sides) HDR 7 POS 2.54mm Solder ST SMD SL? Tube
PDF
/
Buying Options
Total Price: USD $2.11
Unit Price: USD $2.107628
≥1 USD $2.107628
≥10 USD $1.988324
≥100 USD $1.875777
≥500 USD $1.769606
≥1000 USD $1.669439
Inventory: 3094
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status RoHS Compliant
Technical
Contact Pattern RECTANGULAR
Dielectric Withstanding Voltage 800VAC V
Max Voltage Rating (AC) 250V
Body/Shell Style RECEPTACLE
Contact Resistance 15mOhm
Contact Style SQ PIN-SKT
Rated Current (Signal) 3A
Body Depth 0.522 inch
UL Flammability Code 94V-0
Body Breadth 0.26 inch
PCB Contact Pattern STAGGERED
Contact Length - Mating 6.604mm
Number of Contacts 7
Number Of PCB Rows 2
Body Length or Diameter 0.8 inch
Reliability COMMERCIAL
Reference Standard UL
Number of Conductors ONE
Current Rating 3A
Orientation Straight
Pitch 2.54mm
Option GENERAL PURPOSE
Mixed Contacts NO
Filter Feature NO
IEC Conformance NO
DIN Conformance NO
MIL Conformance NO
Subcategory Headers and Edge Type Connectors
Additional Feature WITH TUBE PACKAGING
Voltage - Rated 250V
Gender Male
Number of Rows 1
Color Black
Min Operating Temperature -40°C
Max Operating Temperature 105°C
Connector Type Male Pin
Termination Solder
Pbfree Code yes
JESD-609 Code e3
Published 2011
Physical
Housing Material Plastic
Mount Surface Mount
Contact Plating Gold
Contact Material Bronze
Supply Chain
Factory Lead Time 9 Weeks
